POLARIS 360 BLACK MAX POOL CLEANER

Product Description

POLARIS 360 "BLACK MAX" POOL CLEANER

Key	Part Number	Description	Item Number
1	9-100-1014	E2511 POLARIS 9-100-1014 ALL PURPOSE BAG BAG	E2511
	9-100-1012	E2519 POLARIS 9-100-1012 LEAF BAG FOR 380/360	E2519
	9-100-1015	E2513 POLARIS 9-100-1015 SAND/SILT BAG 380/360	E2513
2	9-100-1152	E2536 POLARIS 9-100-1152 UPPER TURBINE HOUSING	E2536
3	9-100-1114	E2520 POLARIS 9-100-1114 HUB CAP FOR 380/360 (1-EACH)	E2520
4	9-100-5107	E2515 POLARIS 9-100-5107 E-CLIP FOR 380/360 (BAG OF 5)	E2515
5	9-100-1108	E2540 POLARIS #9-100-1108 BALL BRG (380/360/340) SUBST E2540L	E2540
6	C10	E2C10 POLARIS #C-10 MAXTRAX TIRE (380/360/280/180)	E2C10
	C11	E2C11 POLARIS C-11 TIRE, BLACK	E2C11
	C-12	E2C12 POLARIS C-12 TIRE, KRAYTON (380/180/360) (OBSOLETE)	E2C12
7	9-100-1008	E2518 POLARIS 9-100-1008 DOUBLE SIDE WHEEL FOR 380/360	E2518
8	9-100-1017	E2527 POLARIS 9-100-1017 BELT KIT SMALL AND LARGE FOR 380/360	E2527
9	9-100-7011	E2541 POLARIS 9-100-7011 SHIELD BEARING SHIELD BEARING	E2541
10	9-100-1005	Frame, Exchange Only	N/A
11	9-100-5117	E2543 POLARIS 9-100-5117 SCREW S.S. 8-32 PHCR 3/8" (BAG OF 5)	E2543
12	9-100-1139	E2542 POLARIS 9-100-1139 AXLE BLOCK ASSEMBLY FRT & REAR 380/360	E2542
13	9-100-1010	E2608 POLARIS 9-100-1010 TRANSFER PULLEY BELT DIVIDER 380/360	E2608
14	9-100-3135	E2574 POLARIS 9-100-3135 COLLAR BAG TIE (360)	E2574
15	9-100-1007	E2517 POLARIS 9-100-1007 TRANSFER PULLEY, DRIVE SHAFT (380/360)	E2517
16	9-100-5115	E2538 POLARIS 9-100-5115 SCREW S.S. 8-32 X 3/4" PAN HEAD (5/BAG)	E2538
17	9-100-5130	E2616 POLARIS 9-100-5130 AXLE BLOCK LOCK WASHER (BAG OF 4)	E2616
18	9-100-1132	E2571 POLARIS 9-100-1132 DRIVE TRAIN GEAR KIT 380/360	E2571
19	9-100-1170	E2545 POLARIS 9-100-5125 SCREW S.S 8-32 PANHEAD 1/2" (5/BAG)	E2545
20	9-100-1116	E2521 POLARIS 9-100-1116 SINGLE SIDE WHEEL FOR 380/360	E2521
21	C131	E2C31 POLARIS C-131 THRUST JET REPAIR KIT REPAIR KIT	E2C31
22	9-100-7008	E2548 POLARIS 9-100-7008 SWEEP HOSE BARB BARB	E2548
23	B20	E2B20 POLARIS B-20 ADJUSTMENT SCREW	E2B20
24	B15	E2B15 POLARIS #B-15 SWEEP HOSE CLAMP ATTACH CLAMP, WHITE	E2B15
25	9-100-3005	E2611 POLARIS 9-100-3005 BASE WEIGHT 360 FOR 360	E2611
26	9-100-7170	E2570 POLARIS 9-100-7170 HOSE CLAMP 380/360/280/180 (BAG OF 6)	E2570
27	9-100-7009	E2547 POLARIS #9-100-7009 JET RETAINER (380/360) (2/BAG)	E2547
28	9-100-7014	E2575 POLARIS 9-100-7014 WATER MANAGEMENT SYSTEM FOR 360	E2575
29	9-100-1155	E2561 POLARIS 9-100-1155 HOUSING, TURBINE LOWER	E2561
30	9-100-3105	E2514 POLARIS 9-100-3105 SWEEP TAIL SCRB SCRUBBER 380/360/180 - EACH	E2514
31	9-100-5132	E2546 POLARIS #9-100-5132 FEED O-RING ASSEMBLY O-RING (380/360)	E2546
32	9-100-7016	E2612 POLARIS 9-100-7016 BASE ASSY.	E2612
	9-100-7017	E2613 POLARIS 9-100-7027 BASE ASSY BLACK BLACK (380/360)	E2613
33	9-100-1141	Top Cover, Double Wheel Side	N/A
	9-100-1143	E2627 POLARIS 9-100-1143 TOP COVER DOUBLE WHEEL SIDE BLACK , 360	E2627
34	9-100-1002	E2008 POLARIS 9-100-1002 FEED PIPE/ TIMER ASSB - 360	E2008
35	A20	E2A20 POLARIS A-20 FLOAT FOR HEAD SUBST E3A20	E2A20
36	9-100-1140	Top Cover, Single Wheel Side	N/A
	9-100-1142	E2626 POLARIS 9-100-1142 TOP COVER SINGLE WHEEL SIDE-BLK(380/360)	E2626
37	9-100-1011	E2577 POLARIS 9-100-1011 SWEEP HOSE COMPLETE FOR 360	E2577
	B2	E2B02 POLARIS #B-02 SWEEP HOSE WEIGHT WEIGHT	E2B02
