JACUZZI L225 LASER SAND FILTER 22 1/2IN

Product Description

JACUZZI L225 LASER SAND FILTER 22 1/2" - W/ VALVE 94088225

Key	Part Number	Description	Item Number
1	39-2582-07	JACUZZI DVK-4 DIAL VALVE KIT 4-WAY 1-1/2" THREADED FOR MFM	H9280
1	39-2583-06	JACUZZI DVK-6 REPLACEMENT VALV #39258800R	H9282
1	39-2628-03	JACUZZI DVK-7 DIAL VALVE KIT 7-POSITION	H9293
2	14-0743-06-R	Hex Capscrew 5/16" - 18 x 1" (6 needed)	N/A
3	13-0378-09-R	JACUZZI 13-0378-09-R GASKET FOR MOUNTING TOP MOUNT VALVE	H8301
4	85-8133-00-R	JACUZZI 85-8133-00R LASER TANK FLG ADAPTER FLANGE	H8303
5	47-0434-01-R	JACUZZI 47-0434-01-R COVER O-RING O-RING 5-5/8" X 6-1/8" X1/4	H8255
6	22-5522-02-R	JACUZZI 22-3639-07-R SAND FILL SPOUT FOR MFM15 FILTER	H8305
7	43-0715-05-R	JACUZZI 43-0715-05-R FILTER DIVERT DIVERTER	H8307
8	31-0113-64-R004	Upper Pipe 1-1 /2" x 4-1 /2" PVC (L 160 After 11 /1 /90)	N/A
9	88-1580-01-R	JACUZZI 42-3770-02 UNDERDRAIN ASSY 160L FILTER (SNAP-FIT)	H8309
10	42-3531-02-R	JACUZZI 42-3757-09-R LASER 160 STANDPIPE & MANIFOLD ASSB	H8311
10	42-3510-07-R	JACUZZI 42-3771-01 UNDERDRAIN ASSY 190L FILTER (SNAP-FIT)	H8313
10	42-3516-01-R	JACUZZI 42-3773-09 UNDERDRAIN ASSY 225L FILTER (SNAP-FIT)	H8315
10	42-3518-09-R	JACUZZI 42-3774-08-R STANDPIPE & MANIFOLD ASSY LASER 250	H8317
11	42-3532-01-R	JACUZZI 42-3532-01-R LASER 160 LATERAL KIT (8 EACH)	H8319
11	42-3511-06-R	JACUZZI 42-3511-06 LASER 190/ 225 LATERAL KIT ( SET OF 8 )	H8321
11	42-3517-00-R	JACUZZI 42-3517-00-R LASER 250 LATERAL KIT ( SET OF 8 )	H8322
12	9408-0160-R	JACUZZI 85-5313-04-R8 LATERAL KIT FOR LASER L250C (SET OF 8) NEW STYLE	H8323
12	9408-0190-R	Laser 190 Tank Assembly (Includes 13, 14, 15, 16, 4 & 5)	N/A
12	94080225	Laser 225 Tank Assembly	N/A
12	9408-0250	Laser 250 Tank Assembly	N/A
13	85-8533-00-R	Drain Nozzle	N/A
14	14-4254-09-R	Drain Nozzle Retainer	N/A
15	13-1023-06-R	JACUZZI 13-1023-06-R-010 DRAIN NOZZLE GASKET	H8339
16	85826300R	JACUZZI 85-8263-00-R DRAIN CAP FOR CFR FILTER & EWST	H8108
17	85-8593-00-R	Laser 160,190,225,250 Base Assembly	N/A
18	31-1650-04-R	Laser 160 Backwash Adapter	N/A
18	31-1652-02-R	Laser 190 Backwash Kit	N/A
18	31-1653-01-R	Laser 225 & 250 Backwash Kit	N/A
19	91-9341-82-R	JACUZZI #9193-4182-R PRESSURE GUAGE 0-60 PSI	H8388
19		GAUGE-2" PSI 1/4" IN BACK METAL CASE	H7010
